    Titanium Shell And Tube Heat Exchanger 18KW-4000KW With Nano - Film Technology

    Ask Lasest Price
    Brand Name : GREEFOUN
    Model Number : QXU54S6
    Certification : CE
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100000pieces/year
    Delivery Time : within 15days
    • Product Details
    • Company Profile

    Titanium Shell And Tube Heat Exchanger 18KW-4000KW With Nano - Film Technology

    Evaporator Dry Type Heat


    Exchanger for Rooftop Air Conditioning Unit


    Evaporator Dry Type Heat Exchanger for Rooftop Air Conditioning Unit is suitable for water cooled unit,


    water source heat pump, air cooled pump and air cooled heat pump unit.

    The product is applying for refrigerants of R22, R134a, R407C and R410A etc.

    The referigerating medium is for tap water, underground water, river water and sea water or brine, water

    and glycol solution, sulfate solution, etc.

    For heat exchange tube, copper pipe, copper nickel alloy tube, aluminum brass tube, stainless steel tube,

    etc.

    The shell raw material mainly are seamless steel tube, stainless steel pipe.


    1, Heat exchange tube: four main tube type.

    (1) ∅ within 3/8 "thread copper coil, it is mainly used for" U "type tube evaporator.

    (2) ∅ within 1/2 "threaded straight copper tube, straight tube is mainly used for dry-type evaporator.

    (3) ∅ 1/2 "corrugated straight stainless steel tube, straight tube is mainly used in food industry of dry

    evaporator.

    (4) ∅ 5/8 "inside outside screw wing efficient copper tube, it is mainly used for air precooling industry dry

    evaporator.

    2, shell raw material:

    There are two of the major materials:

    (1) # 20 seamless steel tube, mainly used for all kinds of load - more than 20 ℃ cold agent.

    (2) 304/316 l stainless steel tube, it is mainly used for food and low temperature (below 25 ℃, higher than

    40 ℃) of the refrigerant, 316 l can also be used for cooling load of the sulfate for industry.

    3, interface:

    U SHAPED TUBE DRY EVAPORATOR (SINGLE CIRCUIT)


    CAPACITY: 18KW TO 95KW


    ModelsQXU18S5QXU28S5QXU35S6QXU47S6QXU56S6QXU65S6QXU80S8QXU95S8

    Rated data

    Refrigerant R22

    ti=12°C te=2°C

    tu=7°C Dts=5°C

    QnKW18.628.235.14756658095
    Kcal/h(×103 )162430.240.448.256.768.881.7
    Wnm3 /h46689.611.413.816.4
    Wmm3 /h6.381011.41214.51821
    Dpnbar0.160.290.270.410.350.390.420.46

    ModelsQXU18S5QXU28S5QXU35S6QXU47S6QXU56S6QXU65S6QXU80S8QXU95S8
    Dimension(mm)A8871037127514071431143116311781
    B140140168168168168219219
    C9797107107161161161161
    D690840104011901030118013801530
    E180180200200200200240240
    VentS11/21/21/21/21/21/21/21/2
    OutletS21/21/21/21/21/21/21/21/2
    ConnectionW(DN)4040505065656565
    D1(mm)2222222222222222
    D2(mm)3535353554545454
    P(kg)495872788893125136

    Qn-rated refrigerating capacity Wn-cooling water flow Wm-maximum cooling water flow

    Dpn-pressure drop of recirculating cooling water Dts-overheat temperature


    OIL COOLER


    CAPACITY 3RT TO 40RT


    ModelRefrig. ton (RT)Refrig. ton (104kcal/h)Dimension (mm)Weight (kg)
    DT1TACE
    QXCF3S431.134114635721751407023
    QXCF5S551.189140635721751657033
    QXCF8S683.024168762858901859249
    QXCF10S6103.7801689531049901859258
    QXCF12S6124.5361689531049901859262
    QXCF15S6155.670168127013661001859275

    ModelS (Oil vent)

    P1 (inlet/outlet oil vent)

    Copper pipe external diameter (inch)

    W (inlet/outlet water vent)
    FPT(inner pipe thread)FPT(inner pipe thread)
    QXCF3S41/25/81
    QXCF5S51/25/81-1/2
    QXCF8S61/27/81-1/2
    QXCF10S61/27/81-1/2
    QXCF12S61/21-1/81-1/2
    QXCF15S61/21-1/81-1/2
