    High Efficiency Flooded Heat Exchanger R134a Refrigerant For Water Chiller System

    Ask Lasest Price
    Brand Name : GREEFOUN
    Model Number : QX-410M
    Certification : CE
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100000pieces per year
    Delivery Time : within 15days
    • Product Details
    • Company Profile

    High Efficiency Flooded Heat Exchanger R134a Refrigerant For Water Chiller System

    Full Liquid Type Tube Heat Exchanger for Water Chiller System​


    (SINGLE MACHINE) CAPACITY: 350KW TO 650KW

    ModelsQX-350MQX-370MQX-410MQX-460MQX-530MQX-570MQX-650M
    Refrigerant R22 (or other environmental refrigerants)Refrigerating capacity (KW)350370410460530570650
    Heating capacity (KW)400445480540630690730
    Wam3/h6163.5718091.598.6112.3
    Wbm3/h768088.5100114.3123141
    Dpnbar0.530.550.510.520.550.600.61

    ModelsQX-350MQX-370MQX-410MQX-460MQX-530MQX-570MQX-650M
    Dimension(mm)A2050205020502050235023502540
    A1400400450450450450450
    A2350350380380380380380
    L12200220022002200250025002690
    B1140114013001300130013001300
    B1600600680680680680680
    C1808808870870870870870
    C2808808870870870870870
    D1355355426426426426426
    D2426426480480480480480
    H1280280300300300300300
    H2240240260260260260260

    Inlet/Outlet (diameter)
    Connection

    a/b(DN)125125150150150150150
    c1-2 (mm)35353535424242
    d1(mm)80929292929292
    d2(mm)54676767678080
    Corresponding external oilVolume (L)45505560657075
    WeightP (KG)45158069078692010281150

    Notes: Wa water flow capacity of evaporator Wb water flow capacity of condenser Dpn circulating cooling water

    Refrigerating work position: evaporating temperature 5°C, condensing temperature 34°C, chilled water inlet temperature 12°C and outlet 7°C, cooling water inlet temperature 18°C and outlet 29°C
    Heating work position: evaporating temperature 4.5°C, condensing temperature 50°C, hot water inlet temperature 40°C and 45°C, heat source water inlet temperature 16°C and 7°C.
