    Hydraulic Shell And Tube Heat Exchanger Energy Saving Air Conditioning Equipment

    Ask Lasest Price
    Brand Name : GREEFOUN
    Model Number : QXU320S10
    Certification : CE
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100000pieces/year
    Delivery Time : within 15days
    • Product Details
    • Company Profile

    Hydraulic Shell And Tube Heat Exchanger Energy Saving Air Conditioning Equipment

    Air Conditioning Equipment Tube Heat Exchanger


    Water Cooling Evaporator


    Air Conditioning Equipment Tube Heat Exchanger Water Cooling Evaporator is suitable for water cooled


    unit, water source heat pump, air cooled pump and air cooled heat pump unit.

    The product is applying for refrigerants of R22, R134a, R407C and R410A etc.

    The referigerating medium is for tap water, underground water, river water and sea water or brine, water

    and glycol solution, sulfate solution, etc.

    For heat exchange tube, copper pipe, copper nickel alloy tube, aluminum brass tube, stainless steel tube,

    etc.

    The shell raw material mainly are seamless steel tube, stainless steel pipe.


    1, Heat exchange tube: four main tube type.

    (1) ∅ within 3/8 "thread copper coil, it is mainly used for" U "type tube evaporator.

    (2) ∅ within 1/2 "threaded straight copper tube, straight tube is mainly used for dry-type evaporator.

    (3) ∅ 1/2 "corrugated straight stainless steel tube, straight tube is mainly used in food industry of dry

    evaporator.

    (4) ∅ 5/8 "inside outside screw wing efficient copper tube, it is mainly used for air precooling industry dry

    evaporator.

    2, shell raw material:

    There are two of the major materials:

    (1) # 20 seamless steel tube, mainly used for all kinds of load - more than 20 ℃ cold agent.

    (2) 304/316 l stainless steel tube, it is mainly used for food and low temperature (below 25 ℃, higher than

    40 ℃) of the refrigerant, 316 l can also be used for cooling load of the sulfate for industry.

    3, interface:

    STRAIGHT SINGLE SERIES DRY SPIRAL BAFFLE PLATE EVAPORATOR


    CAPACITY: 750KW TO 1500KW


    ModelsRE750S14RE900S16RE1100S16RE1240S20RE1360S20RE1420S20RE1500S20

    Rated data

    Refrigerant R22

    ti=12°C te=2°C

    tu=7°C Dts=5°C

    QnKW75090011001240136014201500
    Kcal/h(×103 )7008629831076116912581367
    Wnm3 /h121141168230252261289
    Wmm3 /h136158176261275309328
    Dpnbar0.480.540.480.400.460.490.58

    ModelsRE750S14RE900S16RE1100S16RE1240S20RE1360S20RE1420S20RE1500S20
    Dimension(mm)A170170170190190190190
    B377426426480480480480
    C3000286030002860286030003500
    D460530530600600600600
    E400450450500500500550
    F3086298431242984298431243624
    VentS11/21/21/21/21/21/21/2
    OutletS21/21/21/21/21/21/21/2
    ConnectionW(DN)150150150200200200200
    D1(mm)42424254(2)54(2)54(2)54(2)
    D2(mm)929292108108108108
    P(kg)7067538088639219921069

    Qn-rated refrigerating capacity Wn-cooling water flow Wm-maximum cooling water flow

    Dpn-pressure drop of recirculating cooling water Dts-overheat temperature


    STRAIGHT SINGLE SERIES DRY SPIRAL BAFFLE PLATE EVAPORATOR (DOUBLE SYSTEM)


    CAPACITY: 320KW TO 680KW


    ModelsRE320D10RE360D12RE420D12RE470D12RE540D14RE620D14RE680D14

    Rated data

    Refrigerant R22

    ti=12°C te=2°C

    tu=7°C Dts=5°C

    QnKW320360420470540620680
    Kcal/h(×103 )267317361404464533585
    Wnm3 /h53.36272.280.893107116
    Wmm3 /h687081.7100105140145
    Dpnbar0.430.430.350.460.410.470.49

    ModelsRE320D10RE360D12RE420D12RE470D12RE540D14RE620D14RE680D14
    Dimension(mm)A140140150150150170170
    B273273325325355377377
    C2500169024001500269026902860
    D360360406406440460460
    E370370380380400400400
    F2586258624882586277627762946
    VentS11/21/21/21/21/21/21/2
    OutletS21/21/21/21/21/21/21/2
    ConnectionW(DN)100100125125125150150
    D1(mm)35354242424242
    D2(mm)67678080909090
    P(kg)296380398442459654669

    Qn-rated refrigerating capacity Wn-cooling water flow Wm-maximum cooling water flow

    Dpn-pressure drop of recirculating cooling water Dts-overheat temperature


    CONDENSER SERIES SINGLE CIRCUIT


    CAPACITY: 20RT TO 35RT


    ModelRefrig. ton (RT)Refrig. ton (104kcal/h)Dimension (mm)Weight (kg)Max. water flow
    DT1TACE
    QXC20S8207.560219127013809023811311015.8
    QXC25S8259.4502191600171012023811312119.5
    QXC30S83011.3402191600171012023811313423
    QXC35S83513.2302191600171012023811314027.3

    ModelS (Vent)

    P (fluoride inlet)

    Copper pipe diameter (inch)

    L(fluoride outlet)

    Copper pipe diameter (inch)

    W (standard port)W (optional port)
    FPT(inner pipe thread)FPT(inner pipe thread)FPT(inner pipe thread)
    QXC20S81/41-1/87/82-1/22
    QXC25S81/41-1/87/82-1/22
    QXC30S81/41-3/81-1/82-1/22
    QXC35S81/41-5/81-1/82-1/22
